Canoga Perkins Model L312

The Canoga Perkins L312 is a managed UTP to Fiber Ethernet Media Converter. It extends 10BASE-T UTP segments up to 120km over Single Mode fiber. It is designed for installation into Canoga Perkins carrier class UCS platform, and is also available as a standalone for desktop or wall mount installations.

The Canoga Perkins Model L312 10BASE-T To Fiber Media Converter


Features

  • 10Mbps Ethernet Extension up to 120km


  • Signal Retiming and Regeneration to Ensure Data Integrity and Ultra Long Extensions


  • Support for Multimode and Single Mode Fiber


  • Standalone and Rackmount for EdgeAcces UCS1000 / 1001 / 1002 / 1030


  • User-Selectable Link Loss Forwarding, and Link Loss Echo for Fault Detection, Isolation, and Reporting


  • Front Panel LEDs for Visual Status


  • Supports SNMP Through Domain Management Module


  • Hot Swappable and Field Replaceable in all Supported Platforms


  • Built in Comprehensive User Interface as well as Graphics Based Management through CanogaView®


  • NEBS Level III Tested and Certified



Canoga Perkins Model L312
10BASE-T To Fiber
Media Converter
Model L312

LAN Extension Standalone Device

Description

The Canoga Perkins L312 is a managed UTP to Fiber Ethernet Media Converter. It extends 10BASE-T UTP segments up to 120km over Single Mode fiber. It is designed for installation into Canoga Perkins carrier class UCS platform, and is also available as a standalone for desktop or wall mount installations.

The Canoga Perkins L312 is an IEEE 802.3 compliant device available with a variety of Multimode and Single Mode optics options to address a complete spectrum of LAN extension applications. It is NEBS level 3 tested and certified and provides an extremely reliable, yet cost effective solution suitable for the most stringent network deployments.

Through user selectable Link Loss Forwarding, and Canoga Perkins unique Link Loss Echo features, the L312 reliably facilitates the detection, isolation, and reporting of problems. A set of front panel LEDs provide the network manager visual status on the state of the device and the entire link.

The L312 supports SNMP and Telnet Management using the EdgeAccess Domain Management Module (DMM) capable of managing up to 240 modules using a single IP address. The user may monitor activities through the use of the Command Line Interface (CLI) included with the L312 or by using CanogaView®, a graphics based Network Element Manager.



Ordering Information


Rackmount Host Module (holds 1-2 L3xx modules)

1230-2000 Bus Access Module (BAM) card, requires an L3XX-XXXX

 Standalone Enclosure

1030-2100 Standalone Enclosure, holds one L3xx Module, AC power (autoranging 85 to 264 VAC)

A001-9006 Wall mount kit, consists of two brackets and 4 mounting screws

MODEL DESCRIPTION

L312-xxxx UTP to Fiber Ethernet Media Converter w/ RJ45

Fiber Optic Options

L312-1113 10Mbps 850nm MM w/ SC, 10dB

L312-1313 10Mbps 1310nm SM w/SC, 18dB

L312-1323 10Mbps,1310nm SM w/SC, 24dB

L312-1833 10Mbps,1550nm SM w/SC, 30dB

 L312-xxxx UTP to Fiber Ethernet Media Converter w/ RJ45

Fiber Optic Options

L312-1111 10Mbps 850nm MM w/ ST, 10dB

L312-1311 10Mbps 1310nm SM w/ST, 18dB

L312-1321 10Mbps,1310nm SM w/ST, 24dB

L312-1831 10Mbps,1550nm SM w/ST, 30dB
